30U 32U Outdoor Battery Storage Cabinet For Solar Base Station
Product Description
- Strong rack inside to be equipped with telecom equipments, power
source, battery, temperature control device and other
attachments.
- Digital display the temperature-setting, temperature alarm,
temperature parameters inside and outside, and all kinds of other
alarm information, etc.
- Cabinet made of low thermal conductivity and fireproof material
for heat insulation fireproof.
- Can be installed in any difficult places include the top of
mountain and the roof of buildings.
- Wind-proof, sand-proof, rain-proof, sun-proof and anti-theft,
protection level IP65.
- Supportcustom-made.
Structure
Internal Dimension(H*W*D) :Standard 1800*800*800mm
External Dimension(H*W*D) : Standard 2100*900*900mm
Internal Capacity: 18U,22U,24U,27U 30U,32U,35U,37U,40U,42U etc (based on customers
requirements)
Layout : 4 layers construction equipment cabinet
Door :With two doors, with special lock for outdoor cabinet (support
padlock)
Hinge :Embedded
Material: Aluminum with powder coat ,insulation thickness
45mm,insulation cotton material is PEF
Material available: Aluminum,stainless steel,cold steel,galvanized steel etc (based
on customers requirements)
Structure : Assembly
Cable enter method :Bottom φ50*5 or customer requirement.
Color :RAL7035/Pantone428C, powder coating finish
Equipment Installation Method:19" rack
Ingress Protection: IP55
Noise Level :60-65dB
Temperature Control Cooling :500W air conditioner DC 48V
Lighting :LED lamp
48V LED lamps, it will turn on when the door is opened; it will
turn off when the door is closed.
With 2U AC distribution Panel
Working Temperature: -40°C ~ +55°C
Storage Temperature: -50°C ~ + 70°C
Transport Temperature: -50°C ~ +70°C
48V LED lamps, it will turn on when the door is opened; it will
turn off when the door is closed.
Accessory List(options)
| No. | Item | Specifications |
| 1 | Fan | DC48V, START WORK AT 35°C |
| 2 | Power Distribution (PDU) | GRADE B LIGHTNING PROOF
AC INPUT: 63A/2P *1; AC OUTPUT: 16A/1P*4;
DC OUTPUT: 16A/1P*4 or customer requirement |
| 3 | Environment Monitoring Unit | 48VDCCommunication port: RS485, TCP/IP, SNMP optional |
| 4 | Door Sensor | Monitor door open status inside cabinet and provide real time
alarm. |
| 5 | Water Sensor | Monitor water status inside cabinet and provide real time alarm. |
| 6 | Tilt & Shock Sensor | Monitor shock status inside cabinet and provide real time alarm. |
| 7 | Temperature & Humidity Sensor | Monitor temperature and humidity inside cabinet and provide real
time alarm. |
| 8 | Smoke Sensor | Monitor smoke status inside cabinet and provide real time alarm. |
| 9 | Ground Bar | Resistance value: 0.021Ω |
| 10 | Built-in power supply | 150A/200A/300A |
| 11 | Packaging | Wooden case/Export pallet |
Cooling System(Optional)
| No. | Item | Specifications |
| 1 | Air Conditioner | AC220V/DC48V, Cooling capacity 300w, 400w, 600w, 800w, 1000w,
1200w, 1500w, 2000w, 2500w, 3000w, 3500w, 4000w; AC380V,5000w |
| 2 | Heat Exchanger | AC220V/DC48V, Heat transfer 80w/k, 100w/k, 120w/k, 150w/k, 200w/k |
| 3 | Thermoelectric Cooler (TEC) | DC48V, Cooling capacity 100W, 200w, 300w |
| 4 | Fan | DC48V/220V/110V |
