    UPS Battery Charging Outdoor Power Cabinet

    Ask Lasest Price
    Brand Name : Langji
    Model Number : OEC2150-DC500
    Certification : ISO9001, ISO14001 CE, 3C, IP55
    Price : USD 200~500/unit
    Payment Terms : T/T, Western Union, L/C,PayPal
    Supply Ability : 1500 pcs / month
    Delivery Time : 15~25 working days
    • Product Details
    • Company Profile

    UPS Battery Charging Outdoor Power Cabinet

    New Designed Ups Battery Charging Cabinets Outdoor Power Cabinet


    Protect nameOutdoor Telecom Battery Cabinet
    External dimensionH*W*D 2100*900*900mm
    Internal dimensionH*W*D 1800*800*800mm
    MaterialDouble wall galvanized steel,with 50mm EPS or PU heat insulation between the double wall.
    Surface FinishRAL7035 grey
    Ingress ProtectionIP55
    Security designEmbedded door, embedded hinges, 4-point security lock
    DoorOne front door ,with 10mm thickness rubber cotton on the internal door panel
    Cable entry methodCable entries from the bottom
    Grounding protectionGrounding cooper bar
    StructureAssembled sandwich structure
    LayoutOne compartment,with 4 battery shelves
    Lead acid battery installation MethodBattery shelves,each shelf can load 500KG weight.
    Cabinet coolingOption 1:AC or DC power cabinet air conditioner Option 2:Heat plate exchanger Option 3:TEC cooler
    MOQ1 unit
    Warranty1 Year
    PaymentT/T,L/C,Western Union,PayPal
    Delivery time15~25 working days

    1.Cabinet Dimension:

    Suzhou Langji Company has a very experienced technical team.We support design the cabinet according to the specific dimension and quantity of the lead acid battery.


    2.Cabinet Material:

    Normally our outdoor battery cabinets are made of galvanized steel.With double walls,thickness of outer plare is 1.0~1.5mm, thickness of inner plate is 0.8~1.0mm.There are 50mm EPS heat insulation between the double walls.The cabinet is assembled structure.


    3.Cabinet Structure:

    The cabinet includes 4 battery shelves for placing 4 strings of lead acid batteries. The cabinet includes one 500W DC 48V cabinet air conditioner, installed on front door.


    4.Cabinet Door And Lock:

    The cabinet includes one front door. The cabinet door uses embedded structure. The door opening angle is larger than 110°and the door limit device can limit the opening angle. The lock is theftproof four point lock, supporting padlock.


    5.Cabinet Anti-theft Design:

    Add a mesh door with inside lock system, the mesh door made of SUS304 stainless steel, as the lock system is inside, so it is impossible to destroy from outside.

    UPS Battery Charging Outdoor Power Cabinet


    6.Cabinet Drawing:

    UPS Battery Charging Outdoor Power Cabinet

    7.Cabinet Details:

    UPS Battery Charging Outdoor Power Cabinet
