42U Indoor Server Rack Enclosures Network Cabinet For Data Room
Application
1. Telecommunications rooms
2. Mobile base stations
3. Computer rooms
4. Data Center
5. Control centers
Product Feature
1. Langji company’s patented product.
2. Air condition and heat pipe share a same system, which greatly
improve the efficiency of air conditioning and heat pipe.
3. Air condition and heat pipe system can switch automatically, at
the same time the machine can be remote monitored.
4. Energy saving effect is obvious.
5. Digital temperature controler and high precision of temperature
control.
6. Main components have CE certificates, which can meet EU ROHS
requirements.
7. Module machine design combines each freely according to the room
space make it convenient for transportation and installation.
Product Introduction
Air Condition with heat pipe combines with heat pipe and active
cooling technology together perfectly to achieve the highest
efficiency operation. When the heat pipe system is working, it
introduces outdoor cool air into heat exchanger of heat pipe
through the induced draught fan for energy exchange, then
introduces hot air from equipment room into the heat pipe heat
exchanger for heat exchange through the forced draught fan and then
sends it back to the communication room to cool communication
equipment, thus reducing the compressor’s running time, extending
its life expectancy, saving cost for operation and maintenance to
achieve the purpose of saving energy and reducing consumption. The
Energy Efficiency Ratio of air conditioner is around 3.0, while it
of heat exchanger of heat pipe is around 8.
When the weather is hot, it runs air conditioner. When it is cool,
for example, if there is a 6℃ temperature difference, it runs heat
pipe. The intelligent controller can switch the function between
air conditioner and heat pipe. This series of products can be
widely developed for base station, computer room, IDC data center,
shelter cooling area.
Air conditioner with heat pipe uses a single system to realize the
function of cooling and heat exchange by heat pipe.With the help of
internal and external temperature sensor in this air
conditioner,the intelligent controller can automatically switch the
function between air conditioner and heat pipe.The function of heat
pipe is usually operated firstly to achieve a largest energy saving
effect.This series of products can be widely developed for base
station,equipment room,IDC data center and shelter cooling area.
